VL200 Line Array System Overview
■ A Compact Passive Three-Way Line Source Array Speaker, Featuring Small Size, High Sound Pressure Level, And Lightweight Design.
■ The High-Frequency Section Consists Of Two Neodymium Drivers And A Constant Directivity Horn, Providing Sufficient Mid-High Frequency Sound Pressure Level.
■ The 8-Inch Driver Works With A Specially Designed Waveguide Built Into The Cabinet Structure For Midrange Sound Reinforcement, Reducing The Influence Of The Cabinet And High-Frequency Structure On Midrange Tone, While Improving Midrange SPL And Projection Distance.
■ Two 10-Inch Drivers Are Closely Arranged Around The Midrange Waveguide To Reduce Interference And Diffraction Between Drivers, Effectively Improving Sound Clarity.
■ When The Line Array Speakers Are Connected, The Gaps Between Cabinets Are Minimized, Allowing The Sound Of Each Connected Cabinet To Couple Effectively. The Radiation Characteristics Are Close To An Ideal Line Source.
■ The Line Array Speakers Use A Three-Point Rigging System, With Each Cabinet Offering An Adjustable Angle From 0 To 10 Degrees.
■ The Front Rigging Hardware Uses An Embedded Design. The Pins Are Flush With The Cabinet Surface And Fixed To The Cabinet, Making Packaging Easier And Reducing The Risk Of Loss. When Cabinets Are Connected, The Pins Are Almost Invisible, Giving The Entire Line Array A Strong Integrated Appearance.
■ The Cabinet Is Made From Selected High-Density Birch Plywood, Bonded With Imported Wood Adhesive, And Finished With A Popular Water-Based Speckled Wear-Resistant Spray Coating.
■ The High-Strength Steel Grille With External Dustproof Foam Effectively Reduces Odd-Order Harmonics In The Mid-High Frequency Range, Enhances The Product Appearance, And Protects The System Components.
■ Designed According To The Latest Line Source Theory, It Effectively Improves The Coupling Characteristics Of Each Driver.
■ The Carefully Tuned Crossover Provides Excellent Frequency Response.
■ By Fully Utilizing Wavefront Correction Technology, The System Delivers Clear And Accurate Sound Quality, Bringing An Outstanding Listening Experience To The Audience.
■ Smooth And Accurate Midrange Response Delivers Impressive Reproduction Of Natural Vocals And Music.
■ When Paired With A Dedicated Subwoofer, It Provides Wider Frequency Bandwidth, A More Integrated Sound, And A Stronger Three-Dimensional Sound Image.
■ Widely Used In Theaters, Multi-Function Halls, Banquet Halls, Churches, Schools, Medium And Large Stadiums, Medium And Large Outdoor Performances, Speech Reinforcement, And Other Applications.
■ Widely Used In Lecture Halls, Multi-Function Halls, Churches, Schools, Small And Medium Indoor And Outdoor Performances, Speech Reinforcement, And Other Applications.
