SKU:

TF15

TF15 15-inch 2-Way Full-Range Loudspeaker

Description

Frequency Response: 43Hz–20kHz ±3dB
Sensitivity: 108dB/1W/1m ±2dB
Rated Power: 470W
Peak Power: 1880W
Nominal Impedance: 8Ω
Woofer: 15″ × 1 (190mm magnet, 75mm voice coil)
Tweeter: 3″ × 1 (170mm magnet, 75mm voice coil)
Max SPL: 135dB
Directivity: 80° × 50° (H × V)
Dimensions: 430 × 696 × 450 mm (W × H × D)

GVS AUDIO
View Product Details

describe

■ The Crossover Technology Is Rigorously Designed To Optimize Frequency Response, With A Focus On Enhancing Midrange Vocal Performance.
■ Featuring An 80° x 50° Coverage Angle, It Delivers Uniform And Flat Sound Field Coverage. The Precisely Designed High-Slope Passive Crossover Technology Minimizes Frequency Overlap.
■ The High-Strength Steel Grille Is Backed With Acoustic Fabric, Effectively Protecting The Internal Components.
■ A Pair Of Neutrik® Speakon® NL4MP Connectors Is Equipped On The Rear Panel, Making Loop Connection Between Multiple Speakers More Convenient.
■ Equipped With Up To 19 M8 Rigging Points, It Adapts To Various Complex Installation Environments And Supports Multiple Rigging Accessories.
■ A 35mm Pole Mount Socket Is Built Into The Bottom For Convenient Vertical Installation.
■ The Cabinet Is Made From High-Quality Acoustic Materials, Effectively Reducing Resonance And Sound Coloration To Ensure Pure And Natural Sound.

System Data
System Type: TF15 15-inch 2-way full-range loudspeaker
Frequency Response: 43Hz–20kHz ±3dB
Sensitivity: 108dB/1W/1m ±2dB
Rated Power: 470W
Peak Power: 1880W
Nominal Impedance: 8Ω
LF Driver: 15″ × 1 (190mm magnet, 75mm voice coil)
HF Driver: 3″ × 1 (170mm magnet, 75mm voice coil)
Max SPL: 135dB
Connectors: NL4 Speakon × 2
Enclosure Material: 18mm BB-grade plywood
Finish: Black wear-resistant textured paint
Dispersion: 80° × 50° (H × V)
Dimensions: 430 × 696 × 450 mm (W × H × D)
