Amplified Controllers: 3 Units
AVB Network Switches: 2 Units
Audio Distribution Panel: 1 Unit
Power Distribution Panel: 1 Unit
Accessories: 2 Doors, Cables And 2 Coupling Bars
Analog Input/Link: 2 × 19-Pin CA-COM
AES/EBU Input: 3 × Female XLR3
AES/EBU Link: 3 × Male XLR3
Rear Analog Inputs: 6 × Male XLR3
Rear AES/EBU Inputs: 3 × Female XLR3
Rear AES/EBU Links: 3 × Male XLR3
US AC Input: 30 A NEMA L21-30P, 3P+N+E Male
EU AC Input: 32 A IEC 60309, 3P+N+E Male
EU AC Link Output: 32 A IEC 60309, 3P+N+E Female
AC Presence Indicators: 3 × Dual LED Indicators
US Auxiliary Output: NEMA 5-15 Female
EU Auxiliary Output: Type F Schuko Female
Auxiliary Protection: 10 A Type C Circuit Breaker
Amplifier AC Outputs: 3 × Power Cords With 32 A Power Connectors
AC Input Mode Selector: EU Mode / US Mode
Network Switch AC Outputs: 2 × IEC 60320-1 C13 Female
Analog Output Cables: 6 × XLR3 Male-To-Female, 1.10 m
Analog Cables: 2 × XLR3 Male-To-Female, 0.55 m
AES3 Output Cables: 3 × XLR3 Male-To-Female, 1.10 m
AES3 Link Cables: 3 × XLR3 Male-To-Female, 1.10 m
AES3 Cables: 2 × XLR3 Male-To-Female, 0.55 m
Red CAT7 Ethernet Cables: 3 × 1 m
Black CAT7 Ethernet Cables: 3 × 1 m
RJ45 Blockout Covers: 2 Units
Weight With Equipment: 101.5 kg
Construction Materials: Polyethylene, Aluminium And Steel External Structure With Polycarbonate Doors
